JOVISION 36 HDD Video Storage Server JVS-VS6836-S

In stock

  • Powered by Intel X86 high performance multi-core processor.
  • Supports DDR4 memory, standard 16GB, supports up to 32GB after expansion.
  • Built-in 500G solid-state drive, the server can be equipped with 36 * 2.5-inch/3.5-inch hard drives, and a single drive supports 20TB capacity.
  • Support media forwarding + video storage sharing 850M (or independent scene use).

High Stability

  • Supports long-term storage of recording information with a maximum of 36 disk slots.
  • Supports 850M data write.
  • Supports RAID 0, 50, 60, and JBOD storage modes.

High Reliability

  • Intelligent cooling system is used to effectively reduce noise pollution and create a constant temperature space in the box; fully shielded against electromagnetic radiation, anti-interference, and anti-static (EMI) design.
  • Supports docking with different mainstream manufacturers' management platforms through standard protocols such as IPSAN/NFS.
  • Supports streaming media forwarding, alarm video storage, disk failure alarm, and automatic removal of faulty disks.
  • Supports automatic reconnection of video when network is disconnected, etc.
Category: Brand:

JOVISION 36 HDD Video Storage Server JVS-VS6836-S

OSLinux OS
CPUIntel X86 High performance multi-core processor
Memory16G DDR4 memory, support expansion to 32G
System Drive500G SSD, supports power outage protection
Data DriveSupports up to 36 SATA interfaces, and a single drive supports up to 10TB
Network Interface2 * RJ45 10/100/1000Mbps adaptive Ethernet ports
Network ProtocolRTMP, HLS, TCP/IP, Telnet, etc.
USB PortA total of 4, Front: 2 * USB2.0 Port, Rear: 2 * USB2.0 Port
Display InterfaceFront: 1 * Power Button, 1 * Restart Button, 1 * Hard Disk Indicator Light, 1 * System Fault Light, 2 * Network Indicator LightsRear: 1 * VGA, 1 * Management Network Port, 2 * RJ45 Network Ports
Power Supply100~240V AC, 1300W 1+1 redundant power supply
Power Consumption (Not Including Hard Drive)≤ 85W
Working TemperatureWorking temperature: 0℃～+60℃, storage temperature: -25℃～+75℃
Working HumidityWorking humidity: 10%~90%, Storage humidity: 5%~95%, non-condensing
Dimension4U size, Depth × Width × Height 670mm*433mm*87.6mm
Weight (Not Including Hard Drive)≤ 25kg
Case TypeImported SGCC (galvanized steel plate) ABS panel and punching mesh, hot-swappable hard drive rack
System Configuration
Storage ModeSupports two modes:The default standard storage server mode and the other is Fusion Cloud storage server mode;
Standard storage server mode: general network storage services, such as IPSAN/NFS, can be used by other platforms (Hikvision, Dahua, Uniview, etc.);
Fusion Cloud Storage Server Mode: It can be used as a slave server of Fusion Cloud (only media forwarding and storage services are deployed) and can be used in combination with Fusion Cloud platform server.
Storage CapabilitySupports 36-slot data storage.Supports media forwarding + video storage sharing 850M (can also be used independently in a single scene)
