JVS-ND6616-HD(R2) 16CH H.265 1 SATA NVR

• Supports 16Ch 5.0Megapixel IP Camera
• Adopt the new Vstar GUI , easy to operate and run smoothly
• Support intelligent coding VSMart, greatly reducing storage space
• Improved compatibility for hard disks, and up to 10TB
• Support Intelligent Detection and Human Detection

JVS-ND6616-HD(R2) Bangladesh

Model	JVS-ND6616-HD
Video and Audio
IP Camera Input	16Channel
Audio Input/ Output	1 Channel Output, RCA; 16Channel Audio output through HDMI
Display
Interface	1 HDMI, 1 VGA
Resolution	HDMI: 2560X1440,1920×1080,1440×900,1280×1024,1280×720,1024×768 VGA: 1920×1080,1440×900,1280×1024,1280×720,1024×768
Max Decoding	16ch@ 5.0MP/4.0MP/1080P/960P/720P 25fps
Multi-screen Display	4/5/6/7/8/9/10/11/12/13/14/15/16
OSD	Camera Name & Time, Recording, Alarm Detecting, Remote connection, Volume, Channel Number
Recording
Compression	H.265/H.264
Resolution	16Ch 5.0MP/4.0MP/1080P/960P/720P
Record Mode	Manual, Schedule, MD
Video Detection and Alarm
Trigger Events	Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer
Video Detection	Motion Detection, No Video Detection
Playback and Backup
Sync Playback	1ch 5.0MP, 1ch 4.0MP, 1ch 3.0MP,2ch 1080P
Search Mode	Channel number / recording type / date
Playback Function	Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward, Slow, Step, Full Screen, Snap, Sound On/Off, Zoom
Backup Mode	FAT32 USB Device/Network
Network
Interface	1 RJ-45 port (10/100Mbps)
Network Function	TCP/IP, DHCP, UDP, SMTP, NTP
Smart Phone	iPhone, Android
Storage
SATA	1 SATA interfaces
Capacity	up to 10TB
General
Power Supply	DC 12V
Consumption	≤ 10 W (Without HDD)
Working Temperature	-100C~ 550C
Working Humidity	10 % ~ 90 %
Dimensions	26048227mm
Weight	≤ 1.0kg (Without HDD)
